Dual-MCU Architecture: Dedicated main control MCU plus an independent KNX protocol coprocessor, ensuring stable and reliable KNX bus communication.
KNX Bus Compatibility: Fully compliant with KNX/EIB standards, enabling centralized shading control and advanced scene linkage for curtains and solar shading systems.
Electronic Limit Setting: Replaces traditional mechanical limits with precise ETS-based travel setting, supporting position feedback for real-time opening status monitoring.
Motor Control: Direct-drive tubular motor with forward/reverse rotation, pause, and precise positioning capability.
Additional Functions: Supports RF remote control, status feedback, scene linkage, and scheduled/timer operation.
Integrated End-Cap Design: Modular end-cap construction allows the motor to function as a built-in module, ideal for pre-installation inside roller tubes or shading systems
PRODUCT FEATURES
Dual-MCU Architecture: Dedicated main control MCU plus an independent KNX protocol coprocessor, ensuring stable and reliable KNX bus communication.
KNX Bus Compatibility: Fully compliant with KNX/EIB standards, enabling centralized shading control and advanced scene linkage for curtains and solar shading systems.
Electronic Limit Setting: Replaces traditional mechanical limits with precise ETS-based travel setting, supporting position feedback for real-time opening status monitoring.
Motor Control: Direct-drive tubular motor with forward/reverse rotation, pause, and precise positioning capability.
Additional Functions: Supports RF remote control, status feedback, scene linkage, and scheduled/timer operation.
Integrated End-Cap Design: Modular end-cap construction allows the motor to function as a built-in module, ideal for pre-installation inside roller tubes or shading systems
PRODUCT SPECIFICATION
| Product Name | Model No. | Operating Voltage | Data Base | Working Current | Size |
| KNX Module | YZ-MODULE-KNX-02 | 21~30VDC | YZ14003-01.KNX.A1 | 3mA | 35*18MM |
