Product Features
Position memory after power-off
FSK modulation, ≥200m open-air RF range
3-speed modes (Silent/Comfort/Power) selectable via remote
Anti-surge & anti-interference circuit for precise stroke
Industrial-grade surge resistance
Imported premium MCU for stable & consistent performance
Function Description
RF remote control
External dry contact access
RS485 communication
5 optional dry-contact modes
10-level jog angle adjustment
Technical Specifications
| Product Name | Model No. | Operating Voltage | Rated Torque | Rated Speed | Rated Power | Reception Frequency | Dimension L:204.0 mm | IP Rating |
| Honeycomb Sky Canopy | YZM24T-1/30 Ⅱ-DER | 24VDC | 1Nm | 30rpm | 24W | 868.35MHz (FSK) | L:204.0 mm | IP44 |
